  die cuttingAccording to the different forms of embossing, it is mainly divided into three types: round embossing, round embossing, and flat embossing. According to the placement form of the template, it can be divided into two types: vertical and horizontal. At present, circular pressing is being accepted and applied by more and more manufacturers. The working parts of both the platen and the cutting mechanism of the circular die-cutting machine are cylindrical. During operation, the paper feeding roller sends the material between the die-cutting platen drum and the pressure drum, and the two clamp it to perform die-cutting on the drum. The die-cutting platen drum rotates once, forming a working cycle.
  Multi station circular cutter die-cutting machine is an efficient and high-precision processing equipment. The device is widely used for die-cutting electronic adhesive accessories such as mobile phones, digital cameras, and computers. It has the advantages of multi-layer composite, multi seat die-cutting, waste discharge, and simultaneous winding and unwinding of multiple groups, advanced technology, reasonable process, compact structure, flexible and convenient operation, and high production efficiency. Strong adaptability to different product processes, with die-cutting quality and production efficiency much higher than other die-cutting methods, it is an ideal choice for improving production capacity and reducing production and operating costs of die-cutting products.
  Introduction to the Function of Circular Knife Die-cutting Machine To adapt to different specifications of die-cutting products, die-cutting equipment can be customized according to the requirements of die-cutting manufacturers. Dual speed function: One device can be used as two devices. Each cutterbed can achieve system switching, with any combination of cutterbeds, flexible settings, independent counting, start stop control, and no mutual impact. Asynchronous function: It can achieve small patches and large patches, reducing costs and increasing efficiency. A normal knife mold uses asynchronous virtual setting of a certain knife axis (sliding material) to make small pieces composite into large products, saving both knife mold costs and material costs.
  The function of cutting (pasting) irregular sheets (graphite sheets): irregular sheets can be cut into regular and unequally spaced sheets, or unequally spaced sheets can be arranged into equally spaced sheets, and then the equally spaced sheets can be accurately composite into the product. Suitable for special materials and complex processes. Multiple sets of asynchronous parameter settings, capable of setting one to four different jump distances, with powerful functions and flexible settings.
  Automatic tracking and adjustment function: It can automatically adjust the cutting size or post press die-cutting, align according to the set size, achieve precise positioning, high automation, and save labor. Independent servo control: It can achieve independent start stop, forward and reverse rotation, proportion/synchronization. Set the following speed arbitrarily. Automatic constant tension control, automatic material cutting protection, torque changes with the size of the coil diameter, maintaining constant tension. Automatic correction function: It can achieve automatic correction of main materials. It has a safety protection function to maximize personal safety. High safety factor, simple and convenient operation. Static electricity removal function: Eliminate material static electricity and dirt, improve die cutting quality.
